TR-DA Tray Deaerator

The TR-DA Tray-Type Deaerator provides efficient removal of oxygen and non-condensable gases through multiple tray stages. Its design ensures thorough deaeration to protect boiler systems from corrosion and extends equipment life. Available with customizable capacity and pressure ratings, the TR-DA fits a variety of applications requiring high-quality treated feedwater.

• Oxygen removal to: 0.005 cc/liter or less
• Carbon dioxide removal: 100%
• Capacity range: 5,000 – 500,000 PPH
• Voltages: 208, 240, 380, 415, 480
• Turn-down ratio: 20:1
• Storage capacity: 10 minutes minimum
• Configuration: 100% makeup or variable condensate return
• Design: Internal stainless steel vent condenser and spray valves
• Vessels rated for 50 PSIG with 1/16 in. corrosion allowance (ASME Code compliant)
