The ST Electric Steam Boiler is a packaged electric resistance steam boiler designed for reliable, on-demand steam in commercial and industrial facilities. Built to stringent industry standards, it supports a wide operating range and uses staged element control to maintain set pressure efficiently across varying loads. For added flexibility, the ST can be configured with factory-installed options, and an optional SCR package provides up to 100:1 turndown to closely follow process demand.
- Steam from 1.5–400 BHP
- Capacities 51–13,800 PPH
- kW Rating 15–4,000 kW
- Pressures 15–300 PSI
- Voltages 208, 240, 380, 415, 480, 600
For install information, specifications and detailed information, download the PDFs below or Find a Rep. If you are ready to purchase this product for your organization, request a quote by filling out the form below.
